BikeProtector

BikeProtector - selective overload protection for bicycle charge

- A 230V 2-way Schuko outlet and a 2-pole RCBO device with Type A 30mA rated Residual current breaker and 6A overload protection with B characteristic.

- BikeProtector, charges bikes without risking unnecessary interruptions by the main fuses. If additional failure as for instance a defect on the cord would happen the Residual part will protect the circuit.

High selectivity is achieved.

- We recommend that the main overload protection (fuse) should be at least 10A with C characteristics.

- Transparent cover above the RCBO for a clear overview and easy to test the device.

- Cable entry at the bottom of the enclosure. Rubber seal for 1 or 2 cables are included

- From rear base there is a cable entry knock-out with mounting possibility over a 60mm flush box.

- Protection by impact resistant thermoplastics approved in protection class IP 44.
